Thin Section Bearings / Stainless Steel Deep Groove Ball Bearings S6900ZZ 10x22x6mm

Ask Lasest Price
Brand Name :	Kentie
Model Number :	S6900ZZ
Certification :	CE/RoHS/ISO9001
Payment Terms :	T/T, Western Union,Paypal, MoneyGram, D/P, D/A, L/C
Supply Ability :	500,000pcs per month
Delivery Time :	2-3 work days

Add to Cart

Product Details
Company Profile

Thin Section Bearings / Stainless Steel Deep Groove Ball Bearings S6900ZZ 10x22x6mm

Thin Section Bearing S6900ZZ Stainless Steel Shielded Ball Bearing 10x22x6mm

S6900ZZ Stainless Steel Ball bearings are made of Stainless steel, lubricated with Grease. The inner diameter is 10mm, outer diameter is 22mm and width is 6mm.

Bearing Model	S6900ZZ bearing
Outer Diameter	22mm
Inner Bore	10mm
Width	6mm
Material	Stainless Steel 420
Seals	ZZ
Lubrication	Grease/oil
Package	Plastic tube

Other bearing available:

Bearing NO	Bore(d)		Diameter (D)		Width (B)		Chamfer		Steel Balls		Load Rating		Weight
Bearing NO	mm inch		mm inch		mm inch		mm inch		Number	Size	Cr N	Cor N	KG
694	4	0.1575	11	0.4331	4	0.1575	0.15	0.006	7	2	960	345	0.0017
695	5	0.1969	13	0.5118	4	0.1575	0.2	0.008	8	2	1080	430	0.0023
696	6	0.2362	15	0.5906	5	0.1969	0.2	0.008	8	2.381	1730	670	0.0036
697	7	0.2756	17	0.6693	5	0.1969	0.3	0.012	9	2.381	1600	710	0.005
698	8	0.315	19	0.748	6	0.2362	0.3	0.012	7	3.5	2240	910	0.0076
699	9	0.3543	20	0.7874	6	0.2362	0.3	0.012	9	2.381	1720	840	0.0085
6900	10	0.3937	22	0.8661	6	0.2362	0.3	0.012	12	2.381	2700	1270	0.01
6901	12	0.4724	24	0.9449	6	0.2362	0.3	0.012	9	3.5	2890	1640	0.012
6902	15	0.5906	28	1.1024	7	0.2756	0.3	0.012	10	3.969	4320	2250	0.018
6903	17	0.6693	30	1.1811	7	0.2756	0.3	0.012	11	3.5	4590	2550	0.019
6904	20	0.7874	37	1.4567	9	0.3543	0.3	0.012	11	3.969	6370	3680	0.038
6905	25	0.9843	42	1.6535	9	0.3543	0.3	0.012	13	3.175	6660	4180	0.044
6906	30	1.1811	47	1.8504	9	0.3543	0.3	0.012	14	4.763	7240	5010	0.05
6907	35	1.378	55	2.1654	10	0.3937	0.6	0.024	14	5.556	10390	7160	0.75
6908	40	1.5748	42	2.4409	12	0.4724	0.6	0.024	14	6.747	13020	9200	0.118
6909	45	1.7717	68	2.6772	12	0.4724	0.6	0.024	15	6.747	13490	10130	0.128
6910	50	1.9685	72	2.8346	12	0.4724	0.6	0.024	16	6.747	13900	10900	0.133
